AVMATRIX HVS0403U Micro 4-Channel SDI & HDMI Video Switcher


Sale priceGH₵9,050
Sold out
Product Highlights
  • 2×HDMI & 2×3G-SDI inputs, support auto-detected
  • 2×HDMI PGM outputs,1×HDMI multiview output, 1×USB type-C output
  • All outputs are configurable and assignable
  • USB for capturing and streaming on PC or Android phone
  • Clearly visible multiview & status page
  • Upstream key: Luma key, Chroma key, 2×PIP/ POP
  • Downstream key and LOGO overlay
  • T-bar/ Auto/ Cut transitions; various effects: WIPE(11×2 patterns)/ MIX/ DIP
  • Audio mixer: 2×SDI, 2×HDMI embedded audio and 2×MIC/ line In; audio delay available
  • Media library: 39 default patterns, 16 imported images, 16 captured images, 2 color generators
  • LAN port for PC software remote control
  • FTB/ MUTE/ STILL/ GPIO for tally



    AVMATRIX HVS0403U Specs

    Available M/E Layers 2 M/E
    Effect Types 1 x Graphic, Transition, Chroma Key, Alpha Key, Luma Key
    Graphics Memory 32 Images
    Downstream Keys 1 x Chroma, Luma, DVE
    Generators 2 x Color
    1 x Pattern
    Audio Mixing 2-Channel Mixing
    Switching Type Pushbutton, Software, T-Bar
    Processing Resolution 1080p
    Color Processing YUV
    Number of Video Input Sources 4
    Video Input Connectors 4 x HDMI Female
    Input Video Format HDMI
    1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
    1080i: 50/59.94/60 fps
    720p: 23.98/24/25/29.97/30/50/59.94/60 fps
    576p: 50 fps
    PAL: 50 fps
    480p: 59.94/60 fps
    NTSC: 59.94/60 fps
    Audio Input Connectors 2 x 1/8" / 3.5 mm TRS Stereo Analog Female
    Input Audio Format Analog
    Embedded Audio Input HDMI: 2-Channel (per Input)
    Video Output Channels 2
    Video Output Connectors 1 x HDMI Female (Program)
    1 x HDMI Female (Monitor)
    1 x USB Type-C (USB Video) Female
    Output Video Format HDMI
    1080p: 24/25/30/50/60 fps
    1080i: 50/60 fps
    USB Type-C
    1080p: 60 fps
    Audio Output Connectors 1 x 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output)
    Output Audio Format Analog
    Embedded Audio Output HDMI: 2-Channel (per Output)
    USB Type-C: 2-Channel (per Output)
    Multiview Output 4-Way Multiview viaHDMI
    Monitor Output 1 x HDMI
    Other I/O 1 x DE-15/DB-15 Tally Input
    1 x RJ45 LAN Input/Output
    1 x USB Type-A Firmware, Service Input
    Video Standard Compliance SMPTE 259M/292M/424M
    HDCP Support None
    Compatible Services Facebook Live, Livestream, Skype, Twitch, YouTube Live
    Recording Media 1 x USB 2.0 Type-A(External Drives)
    Power Connector 1 x Barrel (7 to 24 VDC) Input
    Power Consumption Device: 12 VDC at 1 A (12 W)
    Power Supply: 12 VDC at 2 A
    Operating Temperature -4 to 140°F / -20 to 60°C
    Storage Temperature -22 to 158°F / -30 to 70°C
    Dimensions 9.63 x 5.64 x 1.75" / 24.45 x 14.32 x 4.45 cm
    Weight 2.3 lb / 1 kg
    Packaging Info
    Package Weight 3.23 lb
    Box Dimensions (LxWxH) 13 x 7.7 x 3.5"
